HT Hytera PD408 DMR handy talky digital dengan harga yang murah dan fitur yang canggih. Cocok digunakan di perkebunan, tambang, lokasi proyek dll
Great voice quality
With its embedded digital technology Hytera PD408 produces outstanding voice quality even in noisy environments and at the outer perimeter of radio coverage.
Better usage of the frequency range
Thanks to the TDMA method, Hytera PD408 makes it possible to configure the available bandwidth with double the channel capacity of conventional analog radio. This has a clear mitigating effect on increasing spectrum scarcity.
Mixed analog and digital channel
This function ensures that Hytera PD408 can detect analog and digital signals and change automatically to the relevant operating mode.
Robust
Hytera PD408 handheld radio is dust and water-resistant according to IP55, and meets the US military standard MIL-STD-810 C/D/E/F/G.
Long battery service life
With a battery service life of up to 16 hours in digital operation, the PD405 is enduring and is thus reliable even when deployed for long periods.
Additional Functions (selection)
- Different operating modes: analog, DMR Tier II or mixed
- Scans digital or analog channels
- Supports pre-programmed text message transmission
- TDMA direct mode allows up to two simultaneous calls, even without repeater
- Voice operated transmit (VOX)
- Small, slim, light: 112 x 54 x 28 mm, weighing only 270 g
- Individual call, group call and all call
Hytera PD408 specifications
|
General data
|
|
|
Frequency range
|
VHF: 136 – 174 MHz
UHF: 400 – 470 MHz |
|
Supported operation modes
|
DMR Tier II in reference to ETSI TS 102 361-1/2/3 |
|
Channel capacity
|
256 (128 analog + 128 digital)
|
|
Number of zones
|
3
|
|
Channel spacing
|
12.5 / 25 kHz
|
|
Operating voltage
|
7.4 V (nominal)
|
|
Battery
|
1500 mAh (lithium-ion battery)
|
|
Battery service life(5-5-90 duty cycle)
|
analog / digital:
approx. 12 / 16 hours (with 1500 mAh) approx. 16 / 22 hours (with 2000 mAh) |
|
Frequency stability
|
±0.5 ppm
|
|
Antenna impedance
|
50 Ω
|
|
Dimensions (H×W×D)
(with standard battery, without antenna) |
112 x 54 x 28 mm
|
|
Weight
|
approx. 270 g
|
|
Programmable keys
|
2
|
|
Transmitter
|
|
|
Transmitting power
|
VHF: 1 / 5 W
UHF: 1 / 4 W |
|
Modulation
|
11 K0F3E at 12.5 kHz
16 K0F3E at 25 kHz |
|
4FSK digital modulation
|
12.5 kHz (data only): 7K60FXD
12.5 kHz (data and voice): 7K60FXW |
|
Interfering signals and harmonics
|
-36 dBm < 1 GHz
-30 dBm > 1 GHz |
|
Modulation limiting
|
±2.5 kHz at 12.5 kHz
±5.0 kHz at 25 kHz |
|
Hum and noise
|
40 dB at 12.5 kHz
45 dB at 25 kHz |
|
Adjacent channel selectivity
|
60 dB at 12.5 kHz
70 dB at 25 kHz |
|
Audio sensitivity
|
+1 dB to -3 dB
|
|
Audio distortion
|
≤ 3%
|
|
Digital vocoder type
|
AMBE +2™
|
|
Receiver
|
|
|
Sensitivity (analog)
|
0.22 μV (12 dB SINAD)
0.22 μV (typical) (12 dB SINAD) 0.4 μV (20 dB SINAD) |
|
Sensitivity (digital)
|
0.22 μV / BER 5%
|
|
Adjacent channel selectivity
TIA-603 ETSI |
60 dB at 12.5 kHz / 70 dB at 25 kHz
60 dB at 12.5 kHz / 70 dB at 25 kHz |
|
Intermodulation
TIA-603 ETSI |
70 dB at 12.5/25 kHz
70 dB at 12.5/25 kHz |
|
Spurious response rejection
TIA-603 ETSI |
70 dB at 12.5/25 kHz
70 dB at 12.5/25 kHz |
|
Hum and noise
|
40 dB at 12.5 kHz
45 dB at 25 kHz |
|
Nominal audio power output
|
0.5 W
|
|
Audio distortion
|
≤ 3 %
|
|
Audio sensitivity
|
+1 dB to -3 dB
|
|
Conducted spurious emission
|
< -57 dBm
|
|
Ambient data
|
|
|
Operating temperature range
|
-30 °C to +60 °C
|
|
Storage temperature range
|
-40 °C to +85 °C
|
|
ESD
|
IEC 61000-4-2 (level 4)
±8 kV (contact discharge) ±15 kV (air discharge) |
|
Protection against dust and moisture
|
IP55
|
|
Shock and vibration resistance
|
MIL-STD-810 C/D/E/F/G
|
|
Relative humidity
|
MIL-STD-810 C/D/E/F/G
|
|
All technical information was determined at the factory and in accordance with the corresponding standards. Subject to change on the basis of continuous development.
|
|
Scope Of Delivery
- PD408 handheld radio
- Hand strap and belt clip
- Charger and switching power adapter
- Lithium-ion battery with 1500 mAh
- Antenna
- Manual
